Field of View:/
Eyepiece diameter:/
Prism Description:BAK4
Water Resistance Level:IPX6
Objective Lens Diameter:/
Lens Coating Description:FMC
Magnification:/
Model Number:WH-50XD Night Vision
Type:Binoculars
Origin:Mainland China
Product name:Digital Night Vision Binoculars Camera Build-in Laser Rangefinder WIFI Hotspot Tracking Outdoor Hunitng Infared Night Vision
Lens focal length:50mm, F=0.8
Resolution:1920x1080
Maximum frame rate:25 frames SEC(1920x1080) )
Electronic amplification:1~8X continuous amplification
Magnification modes:ordinary magnification and picture-in-picture magnification
Display mode:Full color, black and white, and low light
Display:0.5 inch OLED display, 1024x768 resolution
Exit pupil distance:35mm
Eyepiece magnification:15 times
Image resolution:1024x768
Rangefinder:1000m
Ranging wavelength pulse:905nm
Ranging frequency:25-35khz adaptive
Laser divergence Angle:3mrad
Ranging accuracy:±1m
Product size:235x105x85 (mm)
Product weight:≤ 1.2kg
ZIYOUHU Digital Night Vision Riflescope Built-in Rangefinder WIFI Hotspot Track One-key Calibration Outdoor Hunting Monoculars
ZIYOUHU WH-50XD NIGHT VISIOIN
ZIYOUHU WH-50XD series monocular multi-functional low-light night vision system is composed of ultra-low illumination imaging system and high-resolution OLED imaging system. With high integration, small size, light weight and low power consumption, ZIYOUHU WH-50XD series is a cost-effective product for mobile handheld fog penetration and night vision monitoring.
This series of equipment can effectively solve the 24-hour mobile imaging demand day and night, all day support full color, black and white, low light mode can be selected, can switch display function; And has excellent imaging ability, the farthest observation distance of day and night is 1000 meters; It has been successfully used in forest fire fighting, search and rescue, military frontier defense, maritime water conservancy, waterway, nature reserve, public security armed police, airport, cultural relic protection, energy mines and other security areas such as single soldier, single police, single patrol.
Features:
1, Small size, easy to carry, can be used for single hand; Compact structure, built-in Rangefinder, WIFI, hot spot, azimuth, roll Angle, and other groups of sensors.
2, Ttartup time is less than 5s, super long standby up to 7 hours, stable and reliable performance, can work day and night without difference, strong anti-fall and earthquake resistance, suitable for harsh monitoring environment.
3, Can be one button to take photos and video, easy to capture monitoring details; 64 GB (up to 256 GB) of storage space for information transfer and evidence collection.
4. Unique image processing algorithm, obvious noise reduction effect, unique digital enhancement algorithm and picture-in-picture amplification and automatic image stretching algorithm,
5, 1024×768 ultra high resolution OLED eyepiece system, making the system imaging clearer; 1-8 times continuous zoom, longer detection distance, wider range. Full color, black and white, low light mode is optional, brightness and contrast can be adjusted (easier to find targets in extremely harsh environment).
6. Optical materials are made of unconventional materials with strong reliability and stability; The lens is coated with infrared antireflective film and waterproof film for easy wiping and protection.
Specifications:
▶ Lens focal length：50mm, F=0.8
Resolution：1920 x1080
Maximum frame rate：25 frames/SEC (1920x1080)
Color illuminance：0.00lLux
Black and white illumination：0.000lLux
Electronic amplification：1~8 times continuous amplification
Magnification modes: ordinary magnification and picture-in-picture magnification
Display mode：full color, black and white, and low light
There are 5 kinds of lines
Detection range：index for people(1.8m x
0.5m)/for vehicles (2.3m x 2.3m)
Detection range：1000m (typical weather
conditions) / 2500m (typical weather conditions)
Identification distance 280m (typical weather) / 600m (typical weather)
▶ Parameters of the eyepiece
0.5 inch OLED display, 1024×768 resolution
Contrast：1000:1
Exit pupil distance：35mm
Eyepiece magnification：15 times
▶ Image storage
Video Format：MP4
Image storage：JPG
Image resolution：1024x768
Storage capacity：64 (up to 256 GB)
▶ Laser ranging
The range：1000 meters
Ranging wavelength pulse：905nm
Ranging frequency：25-35khz adaptive
Laser divergence Angle：3mrad
Ranging accuracy：±1m
▶ Data sensor
Supports automatic impact recording, which automatically prerecords and saves videos before and after impact. The duration and sensitivity of impact video can be adjusted
Supports one-click gun calibration.
Azimuth sensor：static accuracy 0.05° dynamic 0.1°
Acceleration sensor：2G-60g internal adjustable
Rolling Angle sensor：range ±90° Static accuracy 0.05° dynamic 0.1°
Pitch sensor：range ±90° Static accuracy 0.05° dynamic 0.1°
▶ Physical properties
Waterproof：IP66
Operating temperature：-40℃ ~ +60℃
Storage temperature：-45℃ ~ +65℃
Input voltage：DC5V
Battery capacity：18500A rechargeable lithium 3.7V @ 4080mAH
Working time：>7 hours
Product size：235×85×85 (mm)
Product weight：≤ 1.1kg
