Origin:Mainland China
Technical Parameters:
50.100.120.150.200.250.300.400.500.600.700.800.900.1000.1200.-1500...2000...2500...6000.7000.8000.9000.10000... ...... 30000mm
Comprehensive accuracy: ±0.02%FS, ±0.05%FS, ±0.1%FS
Resolution: Analog quantity: Theoretical infinitesimal, Digital quantity: 0.1 0.04mm
Outlet method: Straight line lead method, Five-core aviation plug-in connector
output signal: 0-20mA, 4~20mA, 0-3.3V, 0~5V, 0~10V, resistance value, encoder (pulse type) RS485 working
voltage: 0~32VDC (according to (Depending on electrical requirements)
Operating temperature: -30~85°C
Vibration resistance: 10g (5...2000 Hz)
Shock resistance: 50g (11 ms)
Displacement speed: ≤1m/s
Pull wire diameter: Φ0.7 Φ1mm
Stretch strength: 3 -5N optional
Insulation resistance: ≥100MΩ (50VDC)
Shell material: All metal—aluminum alloy (insulation oxidation treatment)
Protection level: IP65 IP67 optional
