is_customized:Yes
Model Number:G720 align bga machine
Origin:Mainland China
Certification:CE
4800W automatic align bga reballing station LY G720 solder machine for Laptop Repair
pls refer these videos ,the working princle of our all Bga rework machine are all like this:
Video:
https://youtu.be/X4bAwpM-LMY
https://youtu.be/71-DBp-cfmM
https://youtu.be/rX_J061xtVc
The Features of LY-G720 bga rework station :
1.
HD Optical alignment system
for precisely mounting BGA and components
2.
Touch screen and PLC controlling
to ensure it work stably and reliably.
3.Components mounting
accuracy within 0.01mm
, Repair
success rate 99.9%
4.
Laser Positioning function
for fast positioning the BGA Chip and motherboard
5.Precise Temperature Control,
accuracy within 2
6. Upper temperature zone can
be moved freely
, Second zone can
be adjusted up and down.
7.
Three temperature
zones to heat up independently.
8. Hot air nozzle can be rotated in 360 degree
9.Perfect support
Soldering, Desoldering, Removing and Reballing
the BGA Chip
10. Rework BGA, VGA, CCGA, QFN, CSP, LGA, SMD, etc
11. With
CE certification
, double over temperature
protection function
The Parameter of bga rework station :
Detail Specification
LY-G720 BGA Rework StationDetailed SHOW
Independent 3 heating zones temperature control system
1.The upper and lower hot air heating,which can heat up at the same time from the top of the
component to the bottom of the PCB;bottom IR heating,temperature precision control within ±1
8 segment temperature control independently.
bga welding machine
2.Hot air district heating for BGA and PCB at the same time,and large area IR heater preheating up
for the bottom of PCB to avoid completely PCB deformation during reworking,the upper or lower
temperature zones could be used alone and combine freely the energy of up and lower
heating element. bga welding machine
3.Adopted high precision K-type thermocouple close-loop control and
PID parameter self-setting
system
; bga welding machine
4.temperature curves can be displayed with instant curve analysis function and multi-group
user data can be saved;temperature can be tested precisely through external measurement
interface,curves can be analysed,set and correct on the touch screen at any time.
Precision optical alignment system
Using high definition and adjustable CCD color optical alignment system,beam split,amplification,lessening,fine adjustment and auto focus with the function that automatic color aberration resolution
and brightness adjustment,adjustable image contrast;equipped with 15 " high definition
LCD monitor.
Multi-functional and humanized operation system
1.Adopting the HD touch human-machine interface;upper heating head and mounting head designed 2 in 1;providing many kinds of titanium alloy BGA tuyere can be rotated in 360 degree for easy installation and replacement.
2.X,Y and R angle adopted micrometer fine-tuning,accuracy locating,precision can reach ±0.01mm.
Superior safety protection function
With the alarm function, after the BGA welding the machine can alarm by itself.In the case of temperature abuse, the circuit can power off automatically with the double over-temperature protection.
Temperature parameter having password protection to prevent any modification. bga welding machine.
Free gift :
( because flux is paste ,so package doesn't include flux ,pls kind understand , thanks ! )
1pcs X Direct heating fixtures
1set X 29 PCS heat directly stencils universal
7pcs X 25k solder balls (0.3/0.4/0.5/0.55/0.6/0.65/0.76mm)
1pcs X suction line
1pcs X brush
1pcs X vacuum pen
1pcs X scraper
1pcs X Tweezers
