Cooling system:No
Usage Scenario:Gaming
PCIe VERSION:PCIe 5.0
Support Memory Channels:2
Support Memory Type:DDR5
Support Chipset Models:Intel Z690
Default TDP / TDP:65W
Number OF Therads:24
Unlocked:YES
GPU-built:No
Chip Process:7nanometers
Processor Type:Intel Core i7
Type:Sixteen-Core
Socket Type:LGA 1700
Application:Desktop
Intel Model:i7 13790F BOX
Origin:Mainland China

Security & Reliability
Intel® Standard Manageability (ISM) ‡
Yes
Intel® Control-Flow Enforcement Technology
Yes
Intel® AES New Instructions
Yes
Secure Key
Yes
Intel® OS Guard
Yes
Execute Disable Bit ‡
Yes
Intel® Boot Guard
Yes
Mode-based Execute Control (MBEC)
Yes
Intel® Virtualization Technology (VT-x) ‡
Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡
Yes
Intel® VT-x with Extended Page Tables (EPT) ‡
Yes
Advanced Technologies
Intel® Gaussian & Neural Accelerator
3.0
Intel® Deep Learning Boost (Intel® DL Boost)
Yes
Intel® Speed Shift Technology
Yes
Intel® Turbo Boost Max Technology 3.0 ‡
Yes
Intel® Turbo Boost Technology ‡
2.0
Intel® Hyper-Threading Technology ‡
Yes
Intel® 64 ‡
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States
Yes
Enhanced Intel SpeedStep® Technology
Yes
Thermal Monitoring Technologies
Yes
Intel® Volume Management Device (VMD)
Yes
Package Specifications
Sockets Supported
FCLGA1700
Max CPU Configuration
1
TJUNCTION
100°C
Package Size
45.0 mm x 37.5 mm
Expansion Options
Direct Media Interface (DMI) Revision
4.0
Max # of DMI Lanes
8
Scalability
1S Only
PCI Express Revision
5.0 and 4.0
PCI Express Configurations ‡
Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes
20
Memory Specifications
Max Memory Size (dependent on memory type)
128 GB
Memory Types
Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s
Max # of Memory Channels
2
Max Memory Bandwidth
89.6 GB/s
Supplemental Information
Marketing Status
Launched
Launch Date
Q1'23
Embedded Options Available
No
CPU Specifications
Total Cores
16
# of Performance-cores
8
# of Efficient-cores
8
Total Threads
24
Max Turbo Frequency
5.20 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency ‡
5.20 GHz
Performance-core Max Turbo Frequency
5.10 GHz
Efficient-core Max Turbo Frequency
4.10 GHz
Performance-core Base Frequency
2.10 GHz
Efficient-core Base Frequency
1.50 GHz
Cache
33 MB Intel® Smart Cache
Total L2 Cache
24 MB
Processor Base Power
65 W
Maximum Turbo Power
219 W
Product Collection
13th Generation Intel® Core™ i7 Processors
Code Name
Products formerly Raptor Lake
Vertical Segment
Desktop
Processor Number
i7-13790F
Lithography
Intel 7
Use Conditions
PC/Client/Tablet
