Nominal Capacity:5120WH
Weight:60KG
Voltage:51.2V
Size:560*440*160mm
Application:Home
Model Number:48-100
Type:Li-Ion
Origin:Mainland China
Certification:CE
Parallel:Support 32 Parallel
Cycle Life:≥6000 Cycles
Power:5120Wh
BMS:Smart 16S 100A
Nominal Voltage:51.2V
Maximum Charging Voltage:58.4V
Maximum Charging Current:1C (100A)
Maximum Continuous Discharge Current:1C (100A)
Charging Temperature:0~55℃
Discharging Temperature:-30~60℃
Case:Stainless Steel Case
Buy More Than 2pcs Get 1% Discount + Coupon = Save More Money
FREE VAT ：DE PL ES NL BE IT
Has Been Deducted VAT.
The price seen by others EU countries includes VAT tax, actual
final payment will cut off the VAT Tax
.
The price includes the product, freight and Customs clearance fee,
so there is no need to pay additional taxes.
Guarantee after sale！！
Battery Warranty Time: 10 years (Free and the new parts within 10 years !!)
Forever Professional technical support.
Specifications:
Product Name : 48V 100Ah LiFePO4 Battery Pack
Built-in BMS: 16S 100A
Rate Capacity : 100Ah
Energy Power : 5120Wh
Nominal Voltage : 51.2V
Max Charge Voltage : 58.4V
Maximum Charging Current : 100A (1C)
Maximum Dicharge Current : 100A (1C)
Cycle Life : ≥6000 Cycles
Charging Temperature : 0~55°C
Discharging Temperature : -20~60°C
Dimensions(L*W*H) :560*440*160mm
Weight : 60kg
Panel design
Common interface:
CAN/RS485 * 2
Dial Code
Drawing Code Switch
LCD Control Buttons
Switch:
Soft Switching for convenient using in daily life
What can we do
1. EU US stock, fast shipping
2. Provide a stable and safe 48V battery pack
3. The battery can be connected to multiple brands of inverters, Victron, Pylontech, Goodwe, Growatt, Voltronic, Deye, LXP, Sofar, GinLong, SMA, etc.
4. Common interface CAN/RS485 * 2
5. BMS: built-in 16S 100A
6. Each cell can be observed and controlled by connecting to a computer
7. Double-layer packaging of carton and pearl cotton to ensure that there will be no collision damage during transportation
Compatible with various brands of inverters
Max 32 Parallel 163kw Power
Solar Home Energy Storage Battery
Widely Application
Solar system
Home energy storage
UPS
Saving money
