Nominal Capacity:10240Wh
Voltage:48V / 51.2V
Model Number:48v 10kw Powerwall
Type:Lifepo4
Origin:Mainland China
Certification:CE,FCC,GMP,RoHS,UL,KC
Support to OEM::Yes
Cycles Time::>6000 times
Warranty::10 years
in parallel::Max 32pcs parallel
Battery management system::Computer remote control
Inverter communication::CAN/RS485*2
Battery cells:Grade A
Battery full discount: Buy 2pcs to enjoy extra total price 1% + coupon.
About customs cost:
1. Shipping method: DDP shipping. There is no additional cost after placing the order. The logistics company delivers home for free.There are no customs fees.
(NO VAT)
2.Countries that cannot place orders. If you need to buy this product, please contact us for inquiry, 24 hours online.
Powerwall Specification:
Nominal Voltage: 48V/51.2V
Nominal Capacity: 200Ah/10kwh
Communication Protocol: CAN /RS485*2
BMS:16S 200A（Max 32pcs in parallel）
Energy: 10240Wh
Cycles Life: ＞6000 Deep Cycles
Max.Charging Current：200A
Discharging Current：200A
Water Dust Resistance：IPX56
Battery Size: (L*W*H)480*830*160mm
Weight: 90Kg
Display:LCD Screen(multifunction setting)
Warranty time: 10 years
Permanent technical support. (Free replacement of new parts within ten years)
Important features:
Built-in battery management system.
CAN / RS485*2 Inverter Communication.
Our battery:
1.New Grade A battery cells, very safe. Has＞6000 cycles life.
2. For our battery pack, we only use the Internal resistance should be less than 0.05Ω and the voltage difference is no more than 0.5mV cell connection.
3. We are using grade A CATL/ EVE/ Lishen brand cells, the cycle time can be over 6,000 times in theory.
Solar photovoltaic system.
Built-in inverter communication protocol.
Compatible inverter brands list:
Victron, Goodwe, Growatt, Voltronic,
Deye, LXP, Sofar, SRNE
MPPsolar, Solis(Gin long), SMA,
TUOBAO, EASUN, Must.
Any More
Powerwall built-in battery management system.
RJ45 to USB PC Monitor.
Voltage/Temperature/SOC/SOH/Cycle/Capacity Per cell.
All around protection and unattended operation.
48v Powerwall supports up to 32pcs parallel communication.
(320KWH) In the future, you can increase the battery capacity at any time.
LiFePO4 Battey Two appearances:
1.Powerwall: Hang on the wall to save space and look good.
2.Rack: Portable, placed in the cabinet or on the floor.
