Plug Type:EU
Is Smart Device:no
is_customized:No
Wavelength:505-520nm
Precision:±3mm/10m
Size:26*14*25cm
Model Number:F95T-XG
Measurement Model:12 lines
Type:Line Lasers
Origin:Mainland China
Certification:CE,FCC,RoHS,WEEE
Waterproof/dustproof:IP54
Laser class:Class 2
Mounting Thread:1/4''&5/8''
Working distance:Approx 30M,3-60M with FD30 receiver
Power supply:3000 mAh Lithium Battery
Operation Time(All Lines ON):4-6 Hours
Self-leveling Range:±4°
>>Parameter:
Model: F95T-XG
IP Rating: IP54
Laser class: Class 2 (IEC/EN 60825-1:2014),
Laser Wavelength: 505-520nm
Horizontal/Vertical Accuracy: ±3mm/10m
Self-leveling Range: ±4°
Mount Size: 1/4'' & 5/8''
Leveling Type: Gravity pendulum
Working time (with all laser beams on): About 4-6 hours
Working range (Radius): 30m/(2-60m with the FIRECORE FD30 laser detector)
Power supply:Rechargeable 3000mAh lithium battery
Power type: Type-C EU plug (send EU plug by default, if you need other plugs, please contact customer service)
Maintenance and after-sales: 1 year warranty
>>Self-leveling function:
On state, when the inclination angle of the instrument exceeds 4º,the laser line will flash quickly so that whether the instrument is flat or not can be detected.
>>Manual mode:
Off state, press and hold the "Manual" key for about 3 seconds until the laser ray appears, and after releasing the operation key, the laser line will flash slowly without alarm, and it can be operated at the angle you choose.Long press "Manual" key to turn off this mode.
>>Pulse mode:
How to use the receiver with F95T-XG laser level?
1: First, turn on laser level's pulse mode——press and hold the receiver button for about 3 seconds, the laser line flashes 3 times and and then enters the pulse mode
2: Second, turn on the receiver and search the laser lines.
When the receiver detects the laser line, it will make "Beep" sounds.
